DeatschWerks Fuel Filter -8AN, 10 Micron

The increasing popularity of ethanol-based fuels such as e10 and e85 has created well-documented challenges in fuel system maintenance.  The new DW fuel filters feature an industry first dual-stage magneto-mechanical filter element.  This provides an extra layer of protection by trapping contaminants of corrosion with a neodymium magnet prior to mechanical filtration.

By incorporating pleated, high surface area, stainless steel filtering material, the new DW fuel filters work equally well in non-ethanol based fuels. The stainless steel filters are compatible with a wide range of fuels including pump gas, race gas, MTBE, ethanol, methanol, and diesel. Superior life span, maximum fuel compatibility, and high temperature tolerance give DW stainless filter elements a distinct advantage over competitors’ glass and paper filter elements.

*Filter Housing Features*

* 2” diameter for easy in-line mounting

* 160mm/ 110mm filtration length

* Anodized T6061 aluminum construction

* -8 AN ORB inlet and outlet

*Filter Element Features*

* Dual stage magneto-mechanical filtration

* 35mm neodymium magnet

* Pleated, high surface area stainless steel filter material

* Fully serviceable and reusable

* Available in 10-micron and 100-micron

* Documented pressure drop vs flow on all elements
